Product Summary

The TMS320VC5402PGE100 is a fixed-point digital signal processor. It is is based on an advanced modified Harvard architecture that has one program memory bus and three data memory buses.

Parametrics

Absolute maximum ratings: (1)Supply voltage I/O range:–0.3V to 4.0V; (2)Supply voltage core range:–0.3V to 2.4V; (3)Input voltage range:–0.3V to 4.5V; (4)Output voltage range:–0.3V to 4.5V; (5)Operating case temperature range:–40℃ to 100℃; (6)Storage temperature range:–55℃ to 150℃.

Features

Features: (1)Advanced Multibus Architecture With Three Separate 16-Bit Data Memory Buses and One Program Memory Bus; (2)40-Bit Arithmetic Logic Unit (ALU),Including a 40-Bit Barrel Shifter and Two Independent 40-Bit Accumulators; (3)17- × 17-Bit Parallel Multiplier Coupled to a 40-Bit Dedicated Adder for Non-Pipelined Single-Cycle Multiply/Accumulate(MAC) Operation; (4)Compare, Select, and Store Unit (CSSU) for the Add/Compare Selection of the Viterbi Operator; (5)Exponent Encoder to Compute an Exponent Value of a 40-Bit Accumulator Value in a Single Cycle; (6)Two Address Generators With Eight Auxiliary Registers and Two Auxiliary Register Arithmetic Units (ARAUs); (7)Data Bus With a Bus-Holder Feature.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TMS320VC5402PGE100
TMS320VC5402PGE100

Texas Instruments

Digital Signal Processors & Controllers (DSP, DSC) DSP

Data Sheet

0-1: $6.38
1-25: $6.10
25-100: $4.58
100-250: $4.49
